25G
25G SFP28
optical modules
There are several main types of 25G SFP28 optical modules:
25GBASE-SR: Supports the 25GBASE-SR Ethernet standard, used for short-distance multimode fiber transmission. It utilizes LC interfaces and can achieve a link transmission of up to 100m over multimode fiber.
25GBASE-LR: Supports the 25GBASE-LR Ethernet standard, used for long-distance single-mode fiber transmission. It utilizes LC interfaces and can achieve a link transmission of up to 10km over single-mode fiber.
25GBASE-ER: Supports the 25GBASE-ER Ethernet standard, used for even longer-distance single-mode fiber transmission. It typically utilizes LC interfaces and can achieve a link transmission of up to 40km over single-mode fiber.
25GBASE-ZR: Supports the 25GBASE-ZR Ethernet standard, used for ultra-long-distance single-mode fiber transmission. It typically utilizes LC interfaces and can achieve a link transmission of up to 80km over single-mode fiber.
These provide a variety of choices based on different transmission distances, fiber types, and application scenarios.
Features
● Support data rate up to 25.78125Gb/s
● Hot-Pluggable SFP28 Footprint and duplex LC Connector
● Link transmission distances range from 100m to 80km
● Temperature Range: Commercial:0°C ~70°C Industrial: -40°C ~85°C
● Compliant to IEEE 802.3cc, SFF-8472 and SFF-8419
● Complies with EU Directive 2015/863/EU
● Power consumption
● RoHS 6 compliance
Application
● DWDM 10Gb/s Ethernet
● 10Gb/s SONET/SDH ITU-T G.959.1 P1L1-2D2
● 10Gb/s SONET/SDH ITU-T G.709
● 10 Gb/s OC-192 / STM-64 LR2
● 10GBASE-ZR and 10GBASE-ER
● 80 km 10G Fibre Channel
